- This hinge is completely concealed when the door is closed.
- Available in 2 weight rated models to self-close doors under 132 lbs and 176 lbs.
- Weight rating is per 2 hinges.
- Closing strength is adjustable.
- Crafted in 304 grade Stainless Steel.
- Adjustable in 3 dimensions after installation.
- Hinge opens a maximum of 180 degrees.
- Can work on wood, steel, and aluminum doors and frames.
- Also known as a 3D hinge. Adjustable for height, compression to frame, and side to plumb the door.
- Hold Open & Self Closing Hinges can work together on the same door.
- Finger protection due to a small gap between door and frame.
- Hinges are sold individually.
- Minimum door thickness is 1-3/4".
- Length: 7"
- Door Side Width: 15/16"
- Frame Side Width: 1-1/16"
- Optional Accessories (found under Related Products):
- Router Templates
- Milling Jig
